Gold & Silver Coated Substrates

For use in electrochemistry, biosensors, cell culture and more

AMSBIO offers a range of gold and silver coated substrates including glass slides, coverslips, and silicon wafers, for biological, chemical, electrical, and material science applications. All substrates are cleaned with oxygen plasma prior to coating and metal films are deposited using electron-beam evaporation for precise control of deposition.

Applications of Gold-coated Substrates

Cell Culture:                             Substrates are prepared in an electron beam evaporator that is solely dedicated to the deposition of gold films. This prevents the occurrence of impure metals contaminating the gold films, as is the case when multi-user equipment is used to coat gold substrates

Microarrays:                                   Substrates are prepared in an electron beam evaporator using titanium, not chromium, as the adhesion layer. This avoids the contamination that can occur when a thin layer of chromium is used to promote adhesion of the gold film to an underlying substrate (such as a glass microscope slide), since chromium readily dissolves and diffuses to the surface of the gold film (and can adversely modify the reactivity of the gold).

Surface Plasmon Resonance: Substrates are deposited using an electron beam evaporator, which permits precise control of gold deposition rates and thus the surface roughness. This ensures a high level of control over the thickness and nanometer-scale surface roughness of gold films, as is necessary in order to generate reproducible results with surface plasmon resonance.

Scanning Probe Microscopy: Substrates deposited on mica can be thermally annealed or transferred to epoxy resin (reverse mounting) to form atomically flat surfaces suitable for scanning probe microscopy.

Can't find what you need?

Please contact us with any inquiries regarding our Gold and Silver Coated Substrates

1 to 10 of 43 Items

ProductsResources

Page
per page
Set Descending Direction
  1. Platinum Coated Silicon Wafer - 100nm Pt over 5nm Ti adhesion layer - 4 inch diameter
    PT.1000.SL0
    1 wafer
    Reagents & Labware, Gold & Silver Coated Substrate......
    $385.00
    View
  2. 10-mm x 10-mm aluminosilicate glass chips coated with 100nm Gold (on Ti adhesion layer)
    AU.1000.GC10
    20 chips
    Reagents & Labware, Gold & Silver Coated Substrate......
    $400.00
    View
  3. 10-mm x 10-mm aluminosilicate glass chips coated with 50nm Gold (on Ti adhesion layer)
    AU.0500.GC10
    20 chips
    Reagents & Labware, Gold & Silver Coated Substrate......
    $340.00
    View
  4. 10-mm x 10-mm aluminosilicate glass chips coated with 10nm Gold (on Ti adhesion layer)
    AU.0100.GC10
    20 chips
    Reagents & Labware, Gold & Silver Coated Substrate......
    $295.00
    View
  5. Fused Silica (UV Grade) Glass Chips - Thickness = 1.0 mm Refractive Index = 1.46
    FSI.10MM.CHIPS
    20 chips
    Reagents & Labware, Gold & Silver Coated Substrate......
    $270.00
    View
  6. N-BK7 Glass Chips - Thickness = 1.0 mm Refractive Index = 1.51
    BK7.10MM.CHIPS
    20 chips
    Reagents & Labware, Gold & Silver Coated Substrate......
    $230.00
    View
  7. SF-10 Glass Chips - Thickness = 1.0 mm Refractive Index = 1.72
    SF.10MM.CHIPS
    10 chips
    Reagents & Labware, Gold & Silver Coated Substrate......
    $255.00
    View
  8. Aluminosilicate Glass Chips - Thickness = 0.7 mm Refractive Index = 1.51
    ALSI.10MM.CHIPS
    20 chips
    Reagents & Labware, Gold & Silver Coated Substrate......
    $190.00
    View
  9. Ultra-Flat Silicon Wafer
    SW.100MM.PRIME
    1 wafer
    Reagents & Labware, Gold & Silver Coated Substrate......
    $70.00
    View
  10. Chips coated with Gold for Template Stripping (100-nm Au without adhesion layer; heat annealed)
    AU.1000.SLC_10MM_NOTI
    20 chips
    Reagents & Labware, Gold & Silver Coated Substrate......
    $790.00
    View

1 to 10 of 43 Items

ProductsResources

Page
per page
Set Descending Direction

Glass slides, coverslips, and silicon wafers for use in cell culture, microarrays, surface plasmon reflectometry and scanning probe microscopy
